X Disk harrow for Claas Xerion 5000 (X Scheibenegge)




The X disc harrow is simply mounted and driven with a specially developed tow coupling for the Xerion. Via the PTO shaft, the rear axle can be moved in and out by means of a
gearbox and the side arms of the harrow can be moved up and down. Since the slip clutch in Xerion drives the PTO shaft, the side arms do not
move completely alone and on, so can be manually helped. The wingspan is 48 cm.

More Informations - Pictures: www.rb-instructions.de
Login to hide ads!


Name X Disk harrow for Claas Xerion 5000 (X Scheibenegge)
Designer RB-instructions
Designed 2017
Inventory 865 parts
Theme Technic > Model > Farm
Already have some of the parts? Use the Build this MOC page to only show the parts you are missing.
Create an account to change the default filters used.

Waiting for Inventory to load

Building Instructions For Sale

This is a Premium MOC, and the instructions to build it are being sold by the designer (RB-instructions) for €9.99

You will receive building instructions of type PDF - Computer Images from the designer once you have organised payment with them.

Help Guide - BI File Types
